一       Product Overview

IDM M3000 is a small portable integrated service access dispatching equipment. It can fuse mobile communication, radio communication, use telephone (FXS), loop trunk (FXO) and other means of communication. Also support multi service optical fiber transmission. Through advanced digital voice processing technology and network encryption transmission technology, different frequency bands interphone, ultra-short wave radio, short-wave radio, traditional PSTN telephone (Public Switched Telephone Network), IP soft phone and traditional IP phone can be accessed seamlessly into the dispatching system network. The device can be used alone, used in concert with dispatching equipment, also used as the remote cluster access gateway of dispatching system. IDM M3000 not only realizes long-distance wireless intercom communication, but also realizes the duplex intercommunication between the wireless equipment and the wired terminal. It solves the problem of intercommunication, dispatching, management of wireless communication network and some other extensive network scheduling problems. Can be applied to the border posts, vehicles, ships and other environments.

二       Product Features

(1).       Can access maximum 24 channels wireless radio equipments, including HF (short wave), VHF (ultra-short wave) SSB station, 350M and 800M cluster intercom.

(2).       2. Support GSM/CDMA, SIP, FXO, magnet telephone and E1 relay interface.

(3).       3. Provide No.1, No.7 and PRI signaling access of 2 channels E1.

(4).       4. Support 2.5G optical interface, used to connect our company's matched multi service optical transmission equipment, offer more service access, can form a ring network, chain network and other networking.

(5).       5. Dispatching function

To provide a variety of standard communication interfaces

To provide automatic and manual connection mode

To provide “one key to call” dispatching function

To provide tablet remote control and synchronous operation function

To provide fast clustering and gregarious command function

To provide the respective level and higher-up bypassing command

To provide command recording and playback function

(6).       6. TDM dispatching system has bandwidth reservation, never busy line, strong anti-interference ability, little speech delay but IP soft switching is easily affected by IP broadcast storm or other unexpected IP traffic.

(7).       Many types of terminal, user terminals can communicate with each other in a variety of ways to meet various emergency requirements

(8).       This dispatching machine has many means to access external communication resources, providing a variety of means of communication directly

(9).       Small size, easy to carry, bring batteries, suitable for field operations, rapid deployment in the field

(10).       The system status and user status are displayed by multicolor indicator, and the system settings and system functions are displayed by LCD screen.

(11).       Dispatching equipment function

三       Audio Features

四       Application
