IDM OMP2400-4E1-30E Datasheet

IDM OMP2400-4E1-30E

1. Description

IDM OMP2400-4E1-30E uses the 2.5G optical fiber transmission bandwidth(G.703 standard), adopt PCM30/31 system. It can support dual fiber mutual backup and phone business interfaces(total 30 channels FXO, FXS, Or magnet), 4 groups physical isolation speed 100M Ethernet (400M), 2 groups physical isolation 1000M Ethernet(2000M), E1(total 1~4 E1 ports), HDMI HD video transmission and other user interfaces. At the same time, the equipment is simple, and can be applied to all kinds of application environment.

2. Function description

1. Standard 19 inch 1U chassis structure, easy to install.

2. Provide 2*2.5G SFP optical interfaces and can be 1+1 optical protection.

3. Provide 30 channels phone

4. Provide 2*1000M Ethernet ports.

5. Provide 4*100M Ethernet ports

6. Provide 4 groups E1(transparent transmission

7. Provide standard SNMP

8. Provide perfect function control switch and alarm indication function.

3. Technical specification

Optical interface

E1 interface

Ethernet interface

FXO/FXS interface

Power supply and power consumption

Working environment

4. Application
